First-class LED technology with reflector light for retrofit lovers. Meanwhile there are for almost all motorcycles LED headlights to retrofit. But the mostly very technical design does not appeal...
LED fog light model 6025
12-24 V, ECE road approval (Reg. 19)
First-class LED technology with reflector light for retrofit lovers.

Meanwhile there are for almost all motorcycles LED headlights to retrofit. But the mostly very technical design does not appeal to everyone. But lovers of the retro look can now breathe a sigh of relief: J.W. Speaker has developed a series of modern LED headlights that combine modern technology and outstanding lighting with the look of old reflector lamps.

Model 6025 is a 4.5-inch fog lamp and available as single light or as 2 light kit.
Factsheets
Standards
Operating voltage [V], nominal 12-24
Operating voltage [V], functional 9-16
Power consumption [W] 8.4
Temperature range [° C] -40 to 65
Protection class IP67
Standards ECE (Reg. 19), SAE J583
EMC (electromagnetic compatibility) ECE (Reg. 10)
Output
Brightness [lm], theoretically 346
Brightness [lm], eff. 291
Brightness [cd] 12300
Beam pattern / lens Nebellicht
Temperature range [° C] -40 to 65
Mounting
Connector Delphi MP280-2M (12059450-B)
Mating connector Delphi MP280-2F (12124819)
Mounting Built-in
Installation dimensions / diameter [mm] 112
Reverse polarity protection 1
Functions
Fog light
Road approval
