LED turn signal model 93

12-24 V, amber, with DRL, with front position light, ECE road approval (Reg. 6, 7, 87)

Model 93 is a high-quality LED headlight in a 90mm standard housing. This common form factor is used in buses, RVs, tractors, trams, motorcycles and various special vehicles.

Features:

- Retrofit for standard 90mm headlights

- 100% ECE- and DOT-compliant road approval.

- Can be used as both built-in and pedestal mount headlight due to separate mounting brackets.

- Meets the tough IP67 and IP69K criteria for the best protection against dust and water ingress.

Model 93 is available as low beam, high beam, fog light and as turn signal. With a variety of mounting brackets, including single and double mounts, as well as 3-point mounting brackets for 1.5mm and 3mm thick mounting frames.

Factsheets

Standards

Operating voltage [V], nominal	12-24
Operating voltage [V], functional	10-30
Power consumption [W]	10.8-14.16 (turn), 7.2-8.4 (DRL), 0.72-0.96 (position)
Temperature range [° C]	-40 to 65
Protection class	IP69K
Standards	ECE (Reg. 6, 7, 87), DOT, FMVSS (108-VI), SAE (J2087, J588)
Transient protection	150 V @ 1 Hz-100 pulses

Output

Temperature range [° C]

-40 to 65

Mounting
